MILITARY HELICOPTER TOW BAR

MODEL HT-60ACA

FOR UH, HH-60 AND AH-64 SERIES WITH SINGLE TAILWHEEL

    The Model HT-60ACA is a light weight aluminum folding tow bar designed for everyday ramp use and can be quickly folded over for easy transporting. Pneumatic wheels take the hassle out of moving to and from the aircraft.

    This tow bar can be used for towing both the UH-60 and the AH-64 by locking the movable pin in the proper position.

    The assembled overall length is approximately 13 ft. This allows turning clearance for the horizontal stabilizer when using a Hummer as a tow vehicle.

SPECIFICATIONS: MATERIAL: 2 PIECE ALUMINUM ASSEMBLED LENGTH: 13 ft. SHIPPING WEIGHT: 69 lbs. FINISH: MIL YELLOW POWDER COAT NSN IN PROCESS

CLICK HERE FOR PARTS BREAKDOWN  IN FORMAT

IF YOU CAN'T READ PDF FILES THEN CLICK HERE
